High Precisison 30KN Mini Full Servo Electric Bending Machine

Yeni

High Precisison 30KN Mini Full Servo Electric Bending Machine

CNC System Axis: D, X Bending Force: 30KN Open Height: 420mm

3 Ton Mini Full Electric Servo Press Brake

Why mini press brake? No need to development punching tools and Rapid proofing.It is very suitable for precision sheet metal parts and mechanical manufacturing parts.





Main Features

  • Dual servo motor Drive

  • 100% Pure electric power, with no oil

  • Using heavy-duty high-precision ball screw

  • Up to 35% faster compared to a hydraulic press brake

  • Friendly user interface



Product Specification

Bending Force 3Ton
Bending Length 400mm
Axis 2
Distance Between Column 300mm
Stroke 120mm
Opening Height 420mm
Back Gauge Stroke 150mm
Main Motro Power 2KW
Motor ishcanto
CNC System ECO-10ES
Approach Speed 200mm/s
Return Speed 200mm/s
Bending Speed 30mm/s
Repeat Positioning Accuracy ±0.01mm
Size 750*750*1980mm
Weight 320kg
